E-glass woven roving
1.Introduction
E-Glass Woven Roving are bidirectional fabric made by interweaving direct roving.
E-Glass Woven Roving are compatible with unsaturated polyester, vinyl ester, epoxy and phenolic resins.
E-Glass Woven Roving are a high-performance reinforcement widely used in hand lay up and robot processes to manufacture boats, vessels, plane and automotive parts, furniture and sports facilities.
2. Feature
Warp and weft yarns are parallel arrangement as flat situation, with uniform tension;
Fiber is aligned with large consistency, stable and easy operation;
Good moldability, fast and complete wet out in resins, resulting in high productivity;
Good transparency and high strength of composite products.
Type
|
Fiber count (ends/cm)
|
Area weight g/m2
|
Thickness mm
|
Width cm
|
Roll weight
|
Tensile strength (N)≥
|
warp
|
weft
|
warp
|
weft
|
EWR270
|
3
|
2.4
|
270+-20
|
0.27
|
100
|
40KG
|
1400
|
1400
|
EWR360
|
3.5
|
3
|
36+-25
|
0.36
|
100
|
40KG
|
2200
|
2200
|
EWR400
|
3.6
|
3.2
|
400+-30
|
0.4
|
100
|
40KG
|
2500
|
2500
|
EWR580
|
2.8
|
2.6
|
580+-50
|
0.58
|
100
|
40KG
|
3850
|
3850
|
EWR600
|
2.6
|
2.5
|
600+-50
|
0.6
|
100
|
40KG
|
4000
|
4000
|
EWR800
|
1.8
|
1.8
|
800+-60
|
0.8
|
100
|
40KG
|
4600
|
4600
|
